Auto Rescue Device
Model |
TPS-10-2P |
TPS-25-2P |
TPS-45-2P |
TPS-60-2P |
|
Capacity (VVVF) |
15KW |
22KW |
40KW |
60KW |
|
AC Input |
380Vac / 415Vac +/- 20% Three Phase Input. 50/60Hz ±10% |
||||
DC Voltage |
48Vdc |
72Vdc |
120Vdc |
144Vdc |
|
Battery |
12V7Ah |
12V 7AH (external battery bank) |
|||
Battery Q’ty |
4 |
6 |
10 |
12 |
|
Charger Type |
Controlled Rectifier CVCC |
||||
Charging Time |
10 Hours for 90% of Full Battery Capacity |
||||
Inverter |
Technology |
IGBT based PWM Sine Wave |
|||
Output Voltage |
220Vac / 240Vac Two PhaseOutput50/60Hz ±0.1Hz |
||||
Efficiency |
85% |
||||
Overload |
105% continuous |
||||
Harmonic Distortion |
<3% on Linear load |
||||
Crest Factor |
4:1 |
||||
Power Factor |
0.8 |
||||
Phase Displacement |
120°±1° |
< Specifications subject to change without prior notice>
